Film Laminated Steel Sheet (Surlyn/PET/PVC/PEN/TPO)
Film Laminated Steel Sheet (Surlyn/PET/PVC/PEN/TPO)
Steel sheets laminated with Surlyn, PET, PVC, PEN and TPO films for scratch-resistant, corrosion-proof and fingerprint-free surfaces on appliances, doors and furniture.
Overview
MESCO supplies film laminated steel sheet, also known as laminated steel or VCM-type steel, for appliance panels, refrigerator doors, washing machines, elevator interiors, door skins and furniture. A polymer film is thermally bonded to the steel surface, delivering premium decorative effects plus durable protection in a single material.
We laminate Surlyn, PET, PVC, PEN and TPO films onto GI, GL, cold rolled or stainless steel substrates, in gloss, matte, textured and embossed finishes, with custom colors and patterns matched to your design.
What Is Film Laminated Steel?
Film laminated steel combines the strength of a steel substrate with the appearance and protection of a polymer film. During production, the film is heated and pressed onto the steel so it bonds permanently without adhesives or solvents. The result resists scratching, corrosion, fingerprints and UV fading, while remaining formable enough for bending and stamping.
Film Options
| Film | Feature | Typical Use |
|---|---|---|
| Surlyn | Glossy, deep color, excellent formability | Refrigerator doors, premium panels |
| PET | Transparent or colored, scratch resistant | White goods, display panels |
| PVC | Versatile patterns and textures | Door skins, furniture, interior panels |
| PEN | High heat resistance | Oven, heater and hot-surface parts |
| TPO | Soft-touch, weather resistant | Architectural and outdoor panels |
Key Features & Benefits
- Scratch resistant: hard film surface survives daily use and handling.
- Fingerprint proof: low-friction, easy-clean surface stays looking new.
- Corrosion protection: the film seals the steel from moisture and chemicals.
- No VOC coating: dry lamination process is environmentally friendly.
- Design freedom: custom colors, textures, wood and stone patterns.
- Formable: laminates bend, draw and stamp without film delamination.
Specifications & Customization
| Parameter | Range / Option |
|---|---|
| Substrate | GI, GL, cold rolled, stainless steel |
| Total thickness | 0.2 - 2.0 mm |
| Film thickness | 0.02 - 0.3 mm |
| Width | 600 - 1500 mm |
| Finish | Gloss, matte, texture, embossed, printed patterns |
| Form | Coil, sheet, cut blank |
Send us your substrate, film type, thickness and target application, and our team will confirm the correct film grade and supply samples for approval before mass production.
Applications
- Refrigerator, washing machine and dishwasher panels
- Elevator interior panels and doors
- Interior and exterior door skins
- Office and home furniture panels
- Air conditioner and heater housings
- Architectural cladding and interior lining
Quality Control
Film adhesion is tested by cross-cut and peel tests, and surface quality is inspected for scratches, bubbles and color consistency. Coil conditions are verified before lamination, and each batch is packed with protective interleaving to prevent transit damage.
Why Choose MESCO?
- 19 years of steel processing experience
- In-house lamination with multiple film grades
- Custom color, texture and pattern matching
- Consistent quality for appliance brands
- Fast samples and responsive support
FAQ
What is the difference between film laminated steel and painted steel?
Film laminated steel bonds a polymer film to the steel, giving deeper gloss, better scratch resistance and fingerprint-free surfaces, while painted steel uses liquid coatings.
Which film is best for refrigerator doors?
Surlyn and PET films are the most popular for refrigerator doors due to their deep gloss and excellent formability.
Can you match a custom color or pattern?
Yes, we match custom RAL or Pantone colors, plus wood, stone, metallic and embossed patterns.
Is film laminated steel suitable for outdoor use?
TPO and weather-resistant film grades are available for outdoor and architectural applications.
Do you supply samples?
Yes, laminated samples with your chosen film and color are provided for approval before production.
