Powder Coated Steel Sheet & Coil
Powder Coated Steel Sheet & Coil
Polyester and epoxy powder coated steel with uniform film thickness, high edge coverage and excellent weathering, available in custom RAL colors.
Overview
MESCO supplies powder coated steel sheet and coil for manufacturers of building facades, electrical enclosures, garage doors, solar frames and household appliances. Powder coating applies a dry, finely ground polymer powder that is electrostatically charged and then cured under heat, forming a dense, uniform and highly durable film that outperforms conventional liquid paint in thickness, edge coverage, impact resistance and environmental safety.
Our powder coating line processes cold rolled, galvanized and galvalume substrates with full surface pretreatment, delivering a consistent finish in any RAL or custom color. Whether you need pre-coated coil for continuous production or cut-to-length sheets for discrete fabrication, MESCO offers flexible supply with strict color management and batch traceability.
What Is Powder Coating on Steel?
Powder coating is a dry finishing process. Electrostatic spray guns charge polymer powder particles, which are attracted to the grounded steel surface and form an even layer before being cured in an oven at 180-200 °C. The powder melts, flows and cross-links into a tough film that is typically 60-300 µm thick. Unlike liquid paint, powder coating contains no solvents, releases almost no VOC, and produces far less waste because overspray can be collected and reused.
The result is a surface that resists scratching, chipping, corrosion, chemicals and weathering, with excellent coverage even on sharp edges and corners where liquid paint tends to pull back.
Coating Options
| Coating Type | Film Thickness | Typical Use |
|---|---|---|
| Polyester | 60 - 120 µm | Architectural panels, doors, outdoor furniture |
| Epoxy | 80 - 200 µm | Enclosures, tanks, corrosion-critical parts |
| Hybrid (epoxy-polyester) | 60 - 150 µm | Indoor appliances, racks, office furniture |
| Super durable polyester | 80 - 300 µm | Facades, coastal buildings, high UV exposure |
Key Features & Benefits
- Thick, uniform film: 60-300 µm with no drips, sags or thin spots, including on edges and corners.
- Superior durability: outstanding impact, scratch and abrasion resistance for demanding environments.
- Excellent weathering: UV-stable pigments and super durable grades for exterior and coastal use.
- Edge and corner coverage: electrostatic attraction ensures full protection where paint fails.
- Environmentally friendly: solvent-free, low VOC, and overspray is reclaimed and reused.
- Color flexibility: any RAL, BS or Pantone color, gloss level and texture on request.
Specifications & Customization
| Parameter | Range / Option |
|---|---|
| Substrate | SPCC, GI, GL, hot rolled pickled |
| Thickness | 0.3 - 3.0 mm |
| Coating type | Polyester, epoxy, hybrid, super durable |
| Film thickness | 60 - 300 µm |
| Color | Any RAL / BS / Pantone, gloss 10-90% |
| Width | 600 - 1500 mm (coil) or cut-to-length sheets |
| Pretreatment | Degreasing, phosphating or chrome-free passivation |
We support both coil coating for continuous stamping lines and sheet coating for discrete parts. For components, we can also accept pre-formed pieces for post-coating with custom jigs and masking.
Applications
- Architectural cladding, roofing and facade panels
- Electrical cabinets, junction boxes and control enclosures
- Garage doors, security doors and rolling shutters
- Solar panel frames and mounting structures
- White goods housings and indoor furniture parts
Quality Control
Surface pretreatment is verified by salt spray testing before coating. Film thickness is measured on flat areas, edges and corners with an electromagnetic gauge; adhesion is checked by cross-cut and impact tests; color is matched against standards under controlled lighting (ΔE ≤ 1.0). Every batch is accompanied by test certificates covering thickness, adhesion, gloss, impact resistance, salt spray hours and bending performance. Third-party inspection (SGS, TUV) is available on request.
Why Choose MESCO?
- In-house powder coating line with complete pretreatment
- Strict color management with batch-to-batch consistency
- 19 years of steel processing, 9 Fortune 500 customers, 60+ countries
- Flexible supply: coil, sheets or coated components
- Technical support for forming, fastening and installation
FAQ
How thick is the powder coating film?
Standard films range from 60 to 120 µm; heavy-duty and super durable grades can reach 200-300 µm.
Can you match my company color?
Yes. Provide a RAL, BS or Pantone code or a physical sample, and we will match it with ΔE ≤ 1.0.
Is powder coated steel suitable for outdoor use?
Yes. Super durable polyester grades offer excellent UV and weathering resistance for facades and coastal environments.
Can you coat pre-formed parts?
Yes. We accept formed components and apply powder coating with custom jigs and masking where required.
What is the minimum order quantity?
Trial quantities are available for color approval, with mass production quoted by substrate, coating and size.
